Product Summary
The DS1631Z is a ±0.5℃ accuracy digital thermometer and thermostat. The DS1631Z digital thermometers provide 9, 10, 11, or 12-bit temperature readings over a -55℃ to +125℃ range. The DS1631Z thermometer accuracy is ±0.5℃ from 0℃ to +70℃ with 3.0V ≤ VDD ≤ 5.5V, and the accuracy is ±1℃ from -10℃ to +85℃ with 3.0V ≤ VDD ≤ 5.5V. The thermostat on all three devices provides custom hysteresis with user-defined trip points (TH and TL). The TH and TL registers and thermometer configuration settings of the DS1631Z are stored in NV EEPROM so they can be programmed prior to installation.
Parametrics
DS1631Z absolute maximum ratings: (1)Voltage on any Pin Relative to Ground: -0.5V to +6.0V; (2)Operating Temperature Range: -55℃ to +125℃; (3)Storage Temperature Range: -55℃ to +125℃; (4)Reflow Oven Temperature: +220℃.
Features
DS1631Z features: (1)Operating Temperature Range: -55℃ to +125℃ (-67°F to +257°F); (2)Temperature Measurements Require No External Components; (3)Output Resolution is User-Selectable to 9, 10, 11, or 12 Bits; (4)Wide Power-Supply Range (+2.7V to +5.5V); (5)Converts Temperature-to-Digital Word in 750ms (max); (6)Multidrop Capability Simplifies Distributed Temperature Sensing Applications; (7)Thermostatic Settings are User-Definable and Nonvolatile (NV).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 DS1631Z |
Maxim Integrated Products |
Board Mount Temperature Sensors |
Data Sheet |
Negotiable |
|
||||||||||||
|
DS1631Z/T&R |
Maxim Integrated Products |
Board Mount Temperature Sensors |
Data Sheet |
Negotiable |
|
||||||||||||
|
DS1631Z+ |
Maxim Integrated Products |
Board Mount Temperature Sensors Digital Thermometer & Thermostat |
Data Sheet |
|
|
||||||||||||
|
DS1631Z+T&R |
Maxim Integrated Products |
Board Mount Temperature Sensors Digital Thermometer & Thermostat |
Data Sheet |
|
|
||||||||||||
