Product Summary
Ideal for space critical applications, the LM4040CIM3X-3.0 precision voltage reference is available in the SOT-23 surface-mount package.Further reducing design effort is the availability of several fixed reverse breakdown voltages: 2.048V, 2.500V, 3.000V, 4.096V, 5.000V, 8.192V, and 10.000V. The minimum operating current increases from 60 μA for the LM4040CIM3X-3.0 to 100 μA for the LM4040-10.0. All versions have a maximum operating current of 15 mA.
Parametrics
LM4040CIM3X-3.0 absolute maximum ratings: (1)Output voltage tolerance: (A grade, 25℃) ±0.1% (max); (2)Low output noise: (10 Hz to 10 kHz) 35 μVrms(typ); (3)Wide operating current range: 60 μA to 15 mA; (4)Industrial temperature range: -40℃ to +85℃; (5)Extended temperature range: -40℃ to +125℃; (6)Low temperature coefficient: 100 ppm/℃ (max).
Features
LM4040CIM3X-3.0 features: (1)Small packages: SOT-23, TO-92 and SC70; (2)No output capacitor required; (3)Tolerates capacitive loads; (4)Fixed reverse breakdown voltages of 2.048V, 2.500V,3.000V, 4.096V, 5.000V, 8.192V, and 10.000V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM4040CIM3X-3.0 |
National Semiconductor (TI) |
Voltage & Current References |
Data Sheet |
|
|
||||||||||||
|
LM4040CIM3X-3.0/NOPB |
National Semiconductor (TI) |
Voltage & Current References |
Data Sheet |
|
|
||||||||||||
