AT29C512-90JC

512K 64K x 8 5-volt, CMOS flash memory, PLCC, 70 ns, 10 ms, Internal Program Control

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.90~0.93 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.90~0.93

PartNumber:: AT29C512-90JC

Brand:: ATMEL Corporation - ATMEL | Pack: PLCC | D/C: 99+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Tienne's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-12

From Other Seller

Part Number:AT29C512-90JC
US $0.90 - 0.93
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
IRFP260N

US $1.30 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT29C512-90JC is a 512K 64K x 8 5-volt only CMOS flash memory. The AT29C512-90JC is a 5-volt only in-system Flash rogrammable and erasable read only memory (PEROM). Its 512K of memory is organized as 65,536 words by 8 bits. Manufactured with Atmels advanced nonvolatile CMOS technology, the AT29C512-90JC offers access times to 70 ns with power dissipation of just 275 mW over the commercial temperature range. When the AT29C512-90JC is deselected, the CMOS standby current is less than 100 μA. The device endurance is such that any sector can typically be written to in excess of 10,000 times.

Parametrics

AT29C512-90JC absolute maximum ratings: (1)Storage Temperature: -65℃ to +150℃; (2)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (3)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (4)Voltage on OE with Respect to Ground: -0.6V to +13.5V; (5)Temperature Under Bias: -55℃ to +125℃.

Features

AT29C512-90JC features: (1)Fast Read Access Time 70 ns; (2)5-volt Only Reprogramming; (3)Sector Program Operation; (4)Internal Program Control and Timer; (5)Hardware and Software Data Protection; (6)Fast Sector Program Cycle Time 10 ms; (7)DATA Polling for End of Program Detection; (8)Low Power Dissipation.
