Product Summary

The TC4469COE is a four-output CMOS buffer/driver. It is an expansion from our earlier single- and dual-output driver. Each driver has been equipped with a two-input logic gate for added flexibility. The applications of the TC4469COE include General-Purpose CMOS Logic Buffer, Driving All Four MOSFETs in an H-Bridge, Direct Small Motor Driver, Relay or Peripheral Drivers, CCD Driver, Pin-Switching Network Driver.

Parametrics

TC4469COE absolute maximum ratings: (1)Supply Voltage: +20V; (2)Input Voltage: (GND – 5V) to (VDD + 0.3V); (3)Maximum Chip Temperature: Operating: +150℃, Storage: – 65℃ to +150℃; (4)Maximum Lead Temperature (Soldering, 10 sec): +300℃; (5)Operating Ambient Temperature Range: C Device: 0℃ to +70℃, E Device: – 40℃ to +85℃, M Device: – 55℃ to +125℃; (6)Package Power Dissipation (TA ≤ 70℃): 14-Pin CerDIP: 840mW, 14-Pin Plastic DIP: 800mW, 16-Pin Wide SOIC: 760mW.

Features

TC4469COE features: (1)High Peak Output Current: 1.2A; (2)Wide Operating Range: 4.5 to 18V; (3)Symmetrical Rise and Fall Times: 25nsec; (4)Short, Equal Delay Times: 75nsec; (5)Latchproof! Withstands 500mA Inductive Kickback; (6)3 Input Logic Choices: AND / NAND / AND + Inv; (7)2kV ESD Protection on All Pins.

Diagrams

TC4469COE logic diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TC4469COE
TC4469COE
Microchip Technology
Power Driver ICs 1.2A Quad LOGIC I/P
Data Sheet
0-1: $1.96
1-10: $1.57
10-25: $1.31
25-100: $1.19
TC4469COE713
TC4469COE713
Microchip Technology
Power Driver ICs 1.2A Quad LOGIC I/P
Data Sheet
0-680: $0.88
680-1000: $0.77
