DS90CR215MTD

TSSOP-48, 3.3V, rising edge, data strobe, LVDS, 21-bit, channel link, CMOS/TTL, 3.3V, 290 mV

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.30~4.49 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $4.30~4.49

PartNumber:: DS90CR215MTD

Brand:: National Semiconductor - NS | Pack: TSSOP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Tienne's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-12

From Other Seller

Part Number:DS90CR215MTD
US $4.30 - 4.49
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The DS90CR215MTD is a 3.3V rising edge data strobe LVDS with 21-bit channel link. The DS90CR215MTD transmitter converts 21 bits of CMOS/TTL data into three LVDS (Low Voltage Differential Signaling) data streams. A phase-locked transmit clock of the DS90CR215MTD is transmitted in parallel with the data streams over a fourth LVDS link. Every cycle of the transmit clock 21 bits of input data are sampled and transmitted. The DS90CR215MTD receiver converts the LVDS data streams back into 21 bits of CMOS/TTL data. At a transmit clock frequency of 66 MHz, 21 bits of TTL data are transmitted at a rate of 462 Mbps per LVDS data channel. Using a 66 MHz clock, the data throughput is 1.386 Gbit/s (173 Mbytes/s).

Parametrics

DS90CR215MTD absolute maximum ratings: (1)Supply Voltage (VCC): 0.3V to +4V; (2)CMOS/TTL Input Voltage: -0.3V to (VCC + 0.3V); (3)CMOS/TTL Output Voltage: -0.3V to (VCC + 0.3V); (4)LVDS Receiver Input Voltage: -0.3V to (VCC + 0.3V); (5)LVDS Driver Output Voltage: -0.3V to (VCC + 0.3V); (6)LVDS Output Short, Circuit Duration: Continuous; (7)Junction Temperature: +150℃; (8)Storage Temperature Range: -65℃ to +150℃; (9)Lead Temperature(Soldering, 4 sec.): +260℃.

Features

DS90CR215MTD features: (1)Single +3.3V supply; (2)Chipset (Tx + Rx) power consumptio<250 mW (typ); (3)Power-dowmode (<0.5 mW total); (4)Up to 173 Megabytes/sec bandwidth; (5)Up to 1.386 Gbps data throughput; (6)Narrow bus reduces cable size; (7)290 mV swing LVDS devices for low EMI; (8)+1V commomode range (around +1.2V); (9)PLL requires no external components; (10)Low profile 48-lead TSSOP package; (11)Rising edge data strobe; (12)Compatible with TIA/EIA-644 LVDS standard; (13)ESD Rating > 7 kV; (14)Operating Temperature: -40 to +85℃.
