Product Summary
The LMV774MTX is a Single, Dual, and Quad low noise precision operational amplifier, which is intended for use in a wide range of applications. Other important characteristics of the LMV774MTX include extended operating temperature range-40℃ to 125℃, tiny SC70-5 package for LMV771, and low input bias current. The applications of the LMV774MTX include Transducer amplifier, Instrumentation amplifier, Precision current sensing, Data acquisition systems, Active filters and buffers, Sample and hold, Portable/battery powered electronics.
Parametrics
LMV774MTX absolute maximum ratings: (1)ESD Tolerance: Machine Model: 200V, Human Body Model: 2000V; (2)Differential Input Voltage: ± Supply Voltage; (3)Supply Voltage (V+–V -): 5.5V; (4)Mounting Temperture: Infrared or Convection (20 sec): 235℃, Wave Soldering Lead Temp (10 sec): 260℃; (5)Storage Temperature Range: -65℃ to 150℃; (6)Junction Temperature: 150℃.
Features
LMV774MTX features: (1)Guaranteed 2.7V and 5V specifications; (2)Maximum VOS (LMV771) 850μV (limit); (3)Rail-to-Rail output swing: w/600Ω load 100mV from rail, w/2kΩ load 50mV from rail; (4)Open loop gain w/2kΩ load: 100dB; (5)VCM: 0 to V+ -0.9V; (6)Supply current (per amplifier): 550μA; (7)Gain bandwidth product: 3.5MHz; (8)Temperature range: -40℃ to 125℃.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LMV774MTX |
National Semiconductor (TI) |
Operational Amplifiers - Op Amps |
Data Sheet |
|
|
||||||||||||
 |
LMV774MTX/NOPB |
National Semiconductor (TI) |
Operational Amplifiers - Op Amps |
Data Sheet |
|
|
||||||||||||
