Product Summary

The J8064D648ANL is a pulsejacktm 1xN GangjackL. The J8064D648ANL LED integrated magnetics connector (ICM) designed to support applications such as: SOHO (ADSL modems), LAN-on-Motherboard (LOM), Hub and Switches.

Parametrics

J8064D648ANL absolute maximum ratings: (1)Size-Height: 13.6 mm; (2)Size-Length: 21.4 mm; (3)Size-Width: 59.1 mm; (4)Contact Material: Phosphor Bronze; (5)Housing Material: Plastic; (6)Lead-Free Status: Lead Free; (7)Mounting Type: Through Hole; (8)Packaging: Tray; (9)RoHS: Compliant.

Features

J8064D648ANL featuture: (1)RoHS peak wave solder temperature rating 260℃; (2)RJ45 1xN, Tab-DOWN 8-pin with internal magnetics; (3)Suitable for CAT 5 and 6 Fast Ethernet cable or better UTP; (4)Internal magnetics: 100% electrically tested for Hipot and functionality.

Diagrams

J8064D648ANL package diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
J8064D648ANL
J8064D648ANL
Pulse
Ethernet & Telecom Connectors 1X4 TAB DOWN 4-CORE
Data Sheet
0-1: $10.45
1-10: $9.83
10-100: $8.60
100-500: $7.84
